Cerclage compression wire

To be able to use cerclage compression wiring, the opposite cortex needs to have contact and must be able to resist compression.

tension band wiring

The figure-of-eight wire loop lies on the lateral surface of the lateral malleolus and acts as a cerclage compression wire when tightened.

Choose a wire of sufficient strength to withstand the tensile forces generated in the figure-of-eight loop (0.8 mm).

Note: “Cerclage compression wiring” was referred to as “Tension band wiring”. We now prefer the term “Cerclage compression wiring” because the tension band mechanism cannot be applied consistently to each component of the fracture fixation. An explanation of the limits of the Tension band mechanism/principle can be found here.

infrasyndesmotic lateral isolated fracture

1. Patient preparation and approach

The patient may be placed in the following positions:

For this procedure a lateral approach is normally used.

lag screw and neutralization plate

2. Reduction

Reduction with small pointed reduction forceps

Reduce the fracture with small pointed reduction forceps.

tension band wiring

Preliminary stabilization

Drill a 1.6 mm K-wire parallel to the fibular axis into the anterior portion of the tip of the lateral malleolus using a 2.0 mm drill sleeve.

Insert the K-wire until its point reaches a minimum of 2.0 cm proximal to the antero-posterior drill hole for the wire.

tension band wiring

Insert a second K-wire

A second 1.6 mm K-wire is inserted parallel to the first one into the posterior portion of the tip of the lateral malleolus.

These two parallel K-wires stabilize the fracture against rotation and will anchor the figure-of-eight wire distally.

Check the reduction under image intensification.

Note Care must be taken to avoid intraarticular insertion of the K-wires - check specifically with the image intensifier.
tension band wiring

3. Fixation


Drill an antero-posterior hole with the 2.0 mm drill bit and protection sleeve, transverse to the long fibular axis, approximately 3 cm proximal to the fracture.

Keep soft-tissue dissection to a minimum.

tension band wiring


In osteoporotic bone, to avoid cutting out of the wire from the drill hole, a bicortical screw may be used as an alternative means of anchoring the proximal end of the wire.

tension band wiring

Wire preparation and insertion

Prepare the 0.8 mm wire by making a loop approximately one third along its length.

Insert the shorter segment of the wire through this drill hole.

tension band wiring

Figure-of-eight configuration

The small pointed reduction forceps can now be removed.

Pass the long segment of the wire (bearing the loop) in a figure-of-eight configuration around the protruding ends of the K-wires.

Twist the free ends of the wire firmly together.

tension band wiring


Some surgeons prefer to use two pieces of wire, twisting the ends together to create the figure of eight loop with a twist on each side.

tension band wiring

Tightening the wire

The wire twist is loosely prepared ensuring that each end of the wire spirals equally, forming a double helix – avoid twisting one wire around the other (straight) wire.

tension band wiring

The wire is tensioned by pulling on the twists.

tension band wiring

The slack is then taken up by further twisting. Repeat this until the desired tension is achieved. Both loops must be tightened at the same time and in the same direction, to achieve equal tension on both arms of the wire.


In osteopenic bone care must be taken to avoid excessive tensioning.

tension band wiring

Prevent later soft-tissue irritation

Trim the twists and turn the ends towards the fibula in order not to irritate the soft-tissues later.

tension band wiring

Sinking the K-wires

Cut the 2 K-wires obliquely approximately 1 cm from their insertion points and, with the help of a bending iron and forceps, bend through 180 degrees.
The K-wires are then driven home, sinking their curved ends into the bone in order to prevent backing out and skin injury.

Take final x-rays in both planes to check results.

infrasyndesmotic lateral isolated fracture

4. Postoperative treatment of infra- and trans-syndesmotic malleolar fractures

A bulky compression dressing and a lower leg backslab, or a splint, are applied, and the limb is kept elevated for the first 24 hours or so, in order to avoid swelling and to decrease pain.

In anatomically reconstructed, stable malleolar fractures, early active exercises and light partial weight bearing are encouraged after day one. In osteoporotic bone, weight bearing should be postponed.

X-ray evaluation is made after 1 week and then monthly until full healing has occurred. Progressive weight bearing is recommended as tolerated.
